P53B liquid seal auxiliary system

P53B liquid seal auxiliary system conforms API 682 for design, manufacture, test and inspection. The whole system can provide fluid for the outer seal of a pressurized dual seal, pre-pressurized bladder accumulator provides pressure to the circulation system. Flow is maintained by an internal pumping ring. Heat is removed from the circulation system by heat exchanger.
System Paramenters
1.Working press. :4.0MPa
2.Working temp. :-19℃～150℃
3.Volume of accumulator:for options
4.Cooling Area:0.4㎡
5.Refilling type:manual filling
6.Pre-charge press. for accumulator:0.8/P1(P1 is seal chamber press.)
System Features
1.Configuration multiplicity, selectable parts: Press. transmitter,Temp. gauge,Press. gauge,etc.
2.Recommended application for Petrochemical, Chemical, Refining.
3.Pressurization is by means of a pre-loaded bladder accumulator, that will ensure stability.
4.The nitrogen is separated from the barrier medium by membranes in the accumulator that cannot get into the barrier medium or process medium.
